Application
This machine is suitable for steaming and coloring pure cotton, polyester cotton, polyester, acrylic and their blended fabrics after printing or baking at high temperature.
Technical characteristics
1. Mechanical door width: 1800-3600mm.
2. Mechanical speed: 10-60m / min.
3. Capacity: 140m, 210m, 280m, 350m, 420m.
4. Steaming temperature: 102 ℃ (steam heating), high temperature: 180 ℃ (heat transfer oil heating)
5. Humidification: automatic humidification, equipped with inlet nozzle.
6. Form: the fabric is hung in a long ring and transmitted loosely.
7. Heating: equipped with hot air circulating fan, the temperature inside the box is uniform.
8. Transmission mode: AC variable frequency drive, synchronous speed regulation with printing machine.

Machine Features
The unique appearance design is refreshing.
Continuous ring forming method, faster!
Built in fan blowing ring, more economical!
Super strong aluminum alloy cloth hanging roller structure, better!
The new structure of steam generator can save a lot of energy and reduce the production cost.
The unique humidification device can quickly cool down and provide enough humidity for the cabinet.
High degree of automation of electrical control, setting all parameters and simple operation.
